About Hydraulic Fly Ash Brick Machine

SHAKTI ENGINEERING

SE-6 Fully Automatic Hydraulic Fly Ash Brick Making Machine

Complete Plant Setup | Manufacturer & Exporter

Shakti Engineering presents the SE-6 Fully Automatic Hydraulic Fly Ash Brick Making Machine, designed for commercial brick manufacturing with higher production capacity. Equipped with a 70-ton hydraulic pressing system and a six-cavity hardened mould, this plant is suitable for businesses looking to manufacture fly ash bricks efficiently.

The complete plant package includes a hydraulic brick press, computerized control panel, pan mixer, conveyor belt, and six-cavity mould.

Key Technical Specifications

• Model: SE-6

• Machine Type: Fully Automatic Hydraulic Fly Ash Brick Making Machine

• Hydraulic Press Capacity: 70 tons

• Production per Cycle: 6 bricks

• Brick Size: 225 100 75 mm (9 4 3 inches)

• Cycle Time: Approximately 20 seconds per cycle

• Estimated Daily Production: 8,5008,600 bricks

• Total Plant Power Requirement: Approximately 21 HP

• Hydraulic Oil Tank Capacity: 350 litres

Machines & Accessories Included

1. Hydraulic Brick Making Machine

• 70-ton hydraulic pressing capacity

• Heavy-duty MS steel plate body

• Heavy-duty hydraulic cylinder and piston

• 7.5 HP Crompton motor for the hydraulic power pack

• 350-litre hydraulic oil tank

2. Computerized Control Panel

• Electronic pressure control system

• Sensor-based monitoring system

• Hydraulic speed control system

3. Pan Mixer

• One pan mixer with approximately 6-foot diameter

• Heavy-duty MS steel construction

• 7.5 HP Crompton motor

• Heavy-duty gearbox

• SKF (ISI) bearings, as specified

• Roller mixing system with scrapers

• Manual material charging and bottom-door discharge

4. Conveyor Belt

• Transfers the prepared mix from the pan mixer to the brick press

• Approximate capacity: 2 tons per hour

• 2 HP Crompton motor, 1440 RPM, as specified

• Gearbox and material-flow regulation arrangement

5. Hardened Brick Mould

• Size: 225 100 75 mm

• Six-cavity configuration

• Hardened mould construction

• Produces six bricks per cycle

Optional Accessories & Consumables

The following items are not included in the standard base plant price unless specifically stated in the quotation.

1. Recycled Plywood Sheets

• Approximate quantity: 1,000 pieces

• Used as brick pallets

• Can be purchased locally or supplied by Shakti Engineering at an additional cost.

2. Hydraulic Oil

• Required tank capacity: 350 litres

• Grade 68 or equivalent, subject to the machine manufacturer's recommendation

• Can be sourced locally or requested as an additional supply item.

3. Hardener Admixture

• Optional chemical additive for concrete/brick production

• May help improve early strength development when suitable for the mix design

• Available as an additional item, subject to the required grade and quantity.

Why Choose Shakti Engineering?

• Complete brick manufacturing plant solution

• Six-brick production per cycle

• Heavy-duty hydraulic pressing system

• Integrated mixing and material-feeding equipment

• Hardened six-cavity mould

• Suitable for commercial brick production

Contact Us for a Quotation

Company: Shakti Engineering
Contact Person: Er. Pankaj Nakum
Mobile / WhatsApp: +91 84698 18494
Email: shaktiengineeringmorbi@gmail.com
Address: Moon Nagar, Panchasar Road, Morbi 363641, Gujarat, India.

Contact us with your production requirements and destination details to receive a suitable plant quotation.

Frequently Asked Questions (Q&A)

Q1. What is the SE-6 Fly Ash Brick Making Machine?

The SE-6 is a fully automatic hydraulic fly ash brick-making plant designed for commercial brick production using a six-cavity mould.

Q2. What is the hydraulic pressing capacity?

The machine has a specified hydraulic pressing capacity of 70 tons.

Q3. How many bricks does it produce per cycle?

The six-cavity mould produces six bricks per cycle.

Q4. What is the standard brick size?

The standard specified brick size is 225 100 75 mm (9 4 3 inches).

Q5. What is the cycle time?

The specified operating cycle is approximately 20 seconds per cycle.

Q6. What is the daily production capacity?

The stated production capacity is approximately 8,5008,600 bricks per day, depending on working hours, material preparation, operating conditions, and production efficiency.

Q7. What is the total power requirement?

The stated plant power requirement is approximately 21 HP. Confirm the final connected load with the supplied motor configuration before installation.

Q8. What is the hydraulic oil tank capacity?

The hydraulic oil tank capacity is 350 litres.

Q9. What equipment is included in the plant?

The described plant includes a hydraulic brick press, computerized control panel, pan mixer, conveyor belt, and one hardened six-cavity mould, subject to the final quotation.

Q10. What is the size of the pan mixer?

The specified pan mixer has an approximate diameter of 6 feet and a 7.5 HP Crompton motor.

Q11. What is the conveyor capacity?

The specified conveyor capacity is approximately 2 tons per hour.

Q12. Are plywood pallets included?

Plywood pallets are optional unless included in the quotation. Approximately 1,000 recycled plywood sheets may be sourced locally or purchased from Shakti Engineering at an additional cost.

Q13. Is hydraulic oil included?

Hydraulic oil is excluded from the standard package unless specified in the quotation. The required quantity should be confirmed against the 350-litre tank capacity and operating requirements.

Q14. Is hardener admixture included?

Hardener admixture is optional and charged separately unless included in the quotation.

Q15. Can I request a quotation for the SE-6 plant?

Yes. Contact Shakti Engineering with your company details, required production capacity, destination, and any additional requirements.

Q16. How can I contact Shakti Engineering?

Call or WhatsApp +91 84698 18494, or email shaktiengineeringmorbi@gmail.com.
